GD&T Symbol: symbol_circularity

Relative to Datum: No

MMC or LMC applicable: No

Drawing Callout:

Circularity drawing callout


The circularity symbol is used to describe how close an object should be to a true circle. Sometimes called roundness, circularity is a 2-Dimensional tolerance that controls the overall form of a circle ensuring it is not too oblong, square, or out of round. Roundness is independent of any datum feature and only is always less than the diameter dimensional tolerance of the part. Circularity essentially make a cross section of a cylindrical or round feature and determines if the circle formed in that cross section is round.

GD&T Tolerance Zone:

Two concentric circles, one inner and one outer, in which all the points within the curcular surface must fall into. The tolerance zone lies on a plane that is perpendicular to the central axis of the circular feature.

Circularity Tolerance Zone

Gauging / Measurement:

Circularity is measured by constraining a part, rotating it around the central axis while a height gauge records the variation of the surface. The height gauge must have total variation less than the tolerance amount.

Relation to Other GD&T Symbols:

Circularity is the 2D version of cylindricity. While cylindricity ensures all the points on a cylinder fall into a tolerance, circularity only is concerned with individual measurements around the surface in one circle. If you think of a stack of coins, circularity would be a measurement around one coin while cylindricity would have to measure the entire stack. (cylindricity is actually a combination of circularity and straightness)

When Used:

Circularity is a very common measurement and is uses in all forms of manufacturing. Any time a part needs to be perfectly round such as a rotating shaft, or a bearing, circularity is usually called out. You will see this GD&T symbol very often on mechanical engineering drawings.


If you had a hole that was around a rotating shaft, Both pieces should be circular and have a tight tolerance. Without circularity, the diameter of the hole and shaft would have to be very tight and more expensive to make.


Example 1: Controlling circularity without GD&T Symbol


Example 2: Controlling both features with circularity allows the diameter tolerances of the part to be opened up much larger.

Final Notes:


Circularity in GD&T is sometimes also referred to as Roundness. Since it is a 2-Dimensional tolerance sometimes multiple sections of the same feature must be measured to ensure that the entire length of a feature is within roundness. Usually two or three measurements are taken to ensure the part meets roundness for each segment of the part.

Statistical Tolerance Stacks:

Because circularity specifies the form of the surface in a specific area it needs to be considered when calculating a statistical tolerance stack. For example, if you have a part with a specified diameter and circularity callout, you must use both in your statistical stack since the the geometric tolerance can contribute to a large part envelope than just the diameter tolerance alone. This will skew the statistical tolerance slightly higher and should be considered since parts are rarely perfectly circular.
